Schematic Parts Book for Bissell Model: 16993 PROHEAT PLUS
Bissell PROHEAT PLUS Model 16993 Schematic Parts List
Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
Popular Supplies
Helpful Repair Videos
| # | Part image | Description | SKU | Price |
| 1 |  | HANDLE UPPER ASSM BK WO DEC Bissell repair part number: 2144406 | 2144406 | $27.78Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 9 |  | HEATER 700 WATTS REPL Bissell repair part number: 2104513 | 2104513 | $38.50Read more |
| 13 |  | SWITCH ROCKER RED REPL Bissell repair part number: 5559125 | 5559125 | $2.97Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 14 | | SWITCH 1 SPD 8 AMP VAC REPL Bissell repair part number: 2108827 | 2108827 | $5.28Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 17 | | CORD RELEASE REPL Bissell repair part number: 2131154 | 2131154 | $6.03Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 23 | | Gasket Extruded 136 in x 27 in Bissell repair part number: 2103418 | 2103418 | $4.32Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 25 |  | BOTTLE ASSEMBLY Bissell repair part number: 2101785 | 2101785 | $16.14Read more |
| 26 | | CAP DETERGENT Bissell repair part number: 2101795 | 2101795 | $8.64Read more |
| 28 | Not Available | Bissell DIVERTERGRAY for model: 16993 PROHEAT PLUS | 2136988 | Not Available |
| 29 | | FLOW INDICATOR ASSY REPL Bissell repair part number: 5556503 | 5556503 | $6.87Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 30 | | GASKET DIVERTER WINST REPL Bissell repair part number: 2114054 | 2114054 | $5.19Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 31 | | DIVERTER ASSEM REPL Bissell repair part number: 2145170 | 2145170 | $4.62Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 32 | | KNOB AUTOMIX REPL Bissell repair part number: 2105108 | 2105108 | $5.19Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 34 |  | Bissell 210-0489 flow indicator base for models 7950 7950-Y 9E00 1698 1698-1 8904 8804 8804M 1699 7901 7920 1699-1 1699-8 1699-A 1699-B 1699-F 1699-P 8905 8910 7901-1 1699-N 8804T 1685 1692 | 2100489 | Original price was: $7.00.$6.00Current price is: $6.00.Add to cart |
| 35 |  | Bissell 214-9871 Window, Base for models: 1692 1699 7901 7920 8905 8910 Proheat 7950 7950-Y 9E00 1698 1698-1 8904 8804 8804M 1699 7901 7920 1699-1 1699-8 1699-A 1699-B 1699-F 1699-P 8905 8910 7901-1 1699-N 8804T 1685 1692 | 2149871 | $18.99Read more |
| 36 | | Single spray tip for bissell 7950 7950-Y 9E00 1685 1692 carpet cleaner shampooer extractor | 2106107 | $9.00Add to cart |
| 38 | | ARM RETAINER LEFT RIGHT Bissell repair part number: 5559113 | 5559113 | $4.53Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 39 |  | Bissel Carpet Cleaner Brush Roller for Models: 1699, 1699-1, 1699-5, 1699-8, 1699-A, 1699-B, 1699-F, 1699-P, 7901, 7920, 8905, 8910, 7901-1 ProHeat Upright 7950, 1699-N and Xtra-Lift 9E007950-Y and Power Steamer Turbo 8804T | 2101128 | $24.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 40 |  | BELTBRUSH 1PK Bissell repair part number: 0150621 | 0150621 | $9.36Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 41 | | ORING FLOW IND DRW REF1697REPL Bissell repair part number: 2106214 | 2106214 | $3.45Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 42 |  | CLEARVIEW WINDOW BK 02165 Bissell repair part number: 2149851 | 2149851 | $10.35Add to cart |
| 43 | | CV BASE W6 ROW TA BRUSH REPL Bissell repair part number: 2151171 | 2151171 | $38.50Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 44 |  | Automix, W/O Knob ProHeat 1697/1698/1699/7901 | 2100107 | $14.95Read more |
| 45 | | Replacement Bissell Piston for Models 1698 1698-1 8904 8804 8804M 1699 7901 7920 1699-1 1699-8 1699-A 1699-B 1699-F 1699-P 8905 8910 7901-1 1699-N 8804T | 2108722 | $9.99Add to cart |
| 47 | | GASKETSHORT DUCT REPL Bissell repair part number: 2104050 | 2104050 | $5.19Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 48 | | COVER BELT BLACK REPL Bissell repair part number: 2132993 | 2132993 | $8.64Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 49 | | COVER MOTOR REPL Bissell repair part number: 2132984 | 2132984 | $5.91Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 50 | | GASKET MOTOR INNER REPL Bissell repair part number: 2104056 | 2104056 | $3.42Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 51 | | GASKET MTR INTAKE REPL Bissell repair part number: 2104051 | 2104051 | $2.97Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 54 | | Bissell Left and Right Proheat 1699 7901 Elevator Levers for models 7950 7950-Y 9E00 1698 1698-1 8904 8804 8804M 1699 7901 7920 1699-1 1699-8 1699-A 1699-B 1699-F 1699-P 8905 8910 7901-1 1699-N 8804T 1685 1692 | 2000010 | $10.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 55 | | NO LONGER AVAILABLE Belt driven non electric pump assy for single brush roller type bissell carpet cleaners models: 1698 1698-1 8904 8804 8804M 1699 7901 7920 1699-1 1699-8 1699-A 1699-B 1699-F 1699-P 8905 8910 7901-1 1699-N 8804T | 2107181 | $39.99Read more |
| 56 | | PUMP BELT PACK 1699 WINSTREPL Bissell repair part number: 2150628 | 2150628 | $10.77Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 57 | | AUTOLOAD RECEIVER REPL Bissell repair part number: 2140710 | 2140710 | $5.82Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 59 | | Bissell 015-9043 Tank with lid and bladder for 1x - 7950 7950-Y 9E00 1698 1698-1 8904 8804 8804M 1699 7901 7920 1699-1 1699-8 1699-A 1699-B 1699-F 1699-P 8905 8910 7901-1 1699-N 8804T 1685 1692 | 0159043 | $49.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 60 | | TANK LID WSCNGSKTandHAND 1698 Bissell repair part number: 0154439 | 0154439 | $25.00Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 61 | | HANDLE TANK REPL Bissell repair part number: 2034435 | 2034435 | $6.96Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 66 | | BLADDER 1697 REPL Bissell repair part number: 2100315 | 2100315 | $18.90Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 67 | | TANKBLADDER AUTOLOAD 1698 Bissell repair part number: 0159041 | 0159041 | $25.00Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 73 | | Tool 3in Tough Stain Non Removable Window Bissell repair part number: 2159155 | 2159155 | $20.13Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 77 |  | Bissell Turbo Tool Brush for Vacuum Cleaners 2036652 | 2036652 | $49.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 80 | | Tool Bare Floor Assy ProHeatPH Intl Bissell repair part number: 2149131 | 2149131 | $8.97Add to cart Product is special order please allow 2-4 weeks for delivery. |
